MTB Dirt and Pumptrack Bike
– Frame: 6061 series aluminum w/ CNC machined 1.5” tapered head tube, internal cable routing, Euro BB with chainstay yoke, and custom CNC machined dropouts
– Top Tube Length: 22.25” (22.97” effective)
– Chain Stay Length 15.25”
– Head Tube Angle 69º
– Seat Tube Angle 72º
– Bottom Bracket Height 12.6”
– Standover Height: 12.5”Parts Spec
– Fork: Manitou Circus Expert, 100mm travel, 41mm offset, 1.5” taper
– Bars: 6061 aluminum, 1” rise, 31” wide (787mm), 31.8mm clamping area
– Stem: Front load, 30mm reach
– Headset: Sealed internal, Zero Stack 44/56, 1-1/8” to 1-1/2” tapered
– Brake: SRAM Level T hydraulic disc
– Rotor: SRAM Centerline 160mm, stainless steel
– Lever: SRAM Level T hydraulic disc w/ hinged lever
– Rear Hub Alloy, fully sealed, 10mm (3/8”) axle, 14-tooth driver
– Front Hub: Alloy, fully sealed, 20mm thru-axle
– Sprocket: SRAM 30-tooth X-Sync 2 direct mount chainring
– Cranks: Truvativ Descendant 6K DUB, 165mm
– BB: SRAM DUB BSA, 73mm
– Chain: KMC Z-510, silver
– Pedals: DUO Brand Resilite platform
– Front Rim: 6061 aluminum, double wall, 32-hole
– Rear Rim: 6061 aluminum, double wall, 32-hole
– Spokes: 14G black w/ black nipples
– Front Tire: 26 x 2.25” Kenda 3-Sixty, 65psi
– Rear Tire: 26 x 2.25” Kenda 3-Sixty, 65psi
– Seat: DUO Brand Waves seat/post combo
– Seat Post: Alloy, 27.2mm diameter, 200mm length
– Seat Clamp: Alloy, quick-release
– Grips: Lock-on, 130mm
– Weight: 27.1 lbs
